Specification

Product model

SENSOR

IMX185(C)

Sensor size

1/1.9"(7.20x4.05)

Pixel size

3.75x3.75

FPS/Resolution

60/1920*1080 (HDMI)

25/1920x1080 (WiFi)

Image storage method

USB flash drive or UVC connected to computer

Fcusing mode

Autofocus Focus

Function

Exposure time

0.06ms~918ms

Exposure

Automatic and manual, providing target brightness settings

White balance

Auto white balance

Parameter settings

Exposure, gain, white balance, color adjustment, sharpness and denoising control

System software

Embedded measurement

PC software

Luckym  software

Working temperature

-10~ 50

Accessories

Storage temperature

-20~ 60

Appearance size

78 mm (3.07”) x 70 mm (2.76”) x 92mm (3.62”)

Single machine weight

0.47 kg (1.0lbs)

Power supply

DC 12V
