Specification

Product name

Sensor

Sony chip

Video

1920*1080@60FPS/1920*1200@60FPS

Pixel size

2μm*2μm

Output interface

HDMI+USB can output measurements simultaneously

Storage mode

U disk or UVC connect to the computer

Power supply

DC-12V/1A

Function

Basic functions

Built-in measurement, photography, video recording, image comparison, and export report

Image quality adjustment

Exposure, color temperature, white balance

Camera function

Mirror, freeze, flip, wide dynamic range, zoom in, zoom out

Grid lines

8 strips horizontally and vertically, color and thickness adjustable and movable

Resolution

1920*1080/1920*1200

Accessories

Camera size

54*54*68mm

Packing size

145*137*70MM
